6-12
CC886
3. Using a flat-nosed punch, drive the bearing out of
the housing.
CC887
Installing Needle Bearing
1. Apply green Loctite #609 to the outside of a new
bearing; then place the new bearing into the hous-
ing.
CC888
2. Using a suitable driver, install the needle bearing
into the gear case housing making sure the bearing
is seated.
NOTE: Do not push the bearing too far into the
housing.
CC889
3. Install the pinion shaft and secure with the existing
48 mm lock collar. Tighten to 125 ft-lb.
CC890
4. Place a punch on the edge of the lock collar in the
oil gallery area; then using a hammer, stake the
lock collar to ensure that the collar will remain
securely tightened.
CC891
5. Install the pinion housing.
Removing/Installing Axle Seal
NOTE: This procedure can be performed on a
rear gear case.
1. Remove the seal using a seal removal tool.
