6-13
6
CC899
2. Using a press, remove the bearing.
CC900
3. Using a press, install the new bearing into the
housing.
CC901
NOTE: Prior to installing the seal, apply High Per-
formance #2 Molybdenum Disulphide Grease to
the seal outside diameter.
4. Using an appropriate seal installation tool, evenly
press the seal into the cover bore until seated.
CF278
5. Repeat steps 1-4 for the opposite side.
INSTALLING DIFFERENTIAL
1. Align the input flange with the front output flange;
then place the differential into position on the
frame and install the cap screws and nuts. Tighten
to 38 ft-lb.
KC291A
2. Install the cap screws securing the flange couplers
together and tighten to 20 ft-lb.
AG925
3. Install the front axles (see Drive Axles in this sec-
tion).
! CAUTION
Make sure the tool is free of nicks or sharp edges or
the seal will be damaged.
