Kyocera ECOSYS FS-C8520MFP Technical Reference Manual

Path Mode Graphics
2-23
The following program illustrates use of this command.
!R! RES;
UNIT C; CMNT Sets unit to cm;
NEWP; CMNT Starts new path;
SPD .5; CMNT Sets line width to .5 cm;
PMZP 2, 2;
PDZP 4, 4;
DPAT 5;
STRK;
PAGE;
EXIT;
Figure 2. 20. Printout of the DPAT Example
In this program, the DPAT command selects the dash pattern with which the line is
stroked.
Predefined dash patterns are selected by specifying values from 1 to 10 for pattern-num-
ber. (A value of 1 specifies solid lines.) User-defined patterns can be selected by specify-
ing values from 11 to 20. The next section explains how to use the SDP (Store Dash
Pattern) command to define your own dash patterns. Specifying an undefined user pat-
tern number results in solid black lines.
User Defined Dash Patterns
Using the SDP command, you can define your own dashed patterns for use in stroking
lines, arcs, and curves. See the following example:
!R! RES;
UNIT P;
SDP 11, 2, 2, 5, 2;
UNIT C; CMNT Sets unit to cm;
NEWP; CMNT Starts new path;
SPD .5; CMNT Sets line width to .5 cm;
PMZP 2, 2;
PDZP 4, 4;
DPAT 11;
STRK;
PAGE;
EXIT;

Kyocera ECOSYS FS-C8520MFP Specifications

General

Category	Printer
Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Speed (B/W)	20 ppm
Print Speed (Color)	20 ppm
Max Print Speed (B/W)	20 ppm
Max Print Speed (Color)	20 ppm
Print Resolution	600 x 600 dpi
Max Print Resolution	9600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Duplex Scanning	Yes
Copy Resolution	600 x 600 dpi
Fax	Yes
Supported Paper Sizes	A3, A4, A5, A6, B5, Letter, Legal
Monthly Duty Cycle	65000 pages
Max Paper Capacity	1600 sheets
Memory	1 GB
Connectivity	USB, Ethernet
Copier Speed (B/W)	20 ppm
Copier Speed (Color)	20 ppm
Copy Speed (B/W)	20 ppm
Copy Speed (Color)	20 ppm
Display	4.3-inch touch screen
