Kyocera ECOSYS M3860idn User Manual

6-2
Using Various Functions > Functions Available on the Machine
Functions Available on the Machine
Copy
To configure the settings for functions, select the function key. By selecting [Functions], other selectable functions will
be shown as a list.
For details on each function, see the table below.
Function key Description
Reference
page
Paper Selection Select the cassette or multi-purpose tray that contains the required paper size. page 6-11
Zoom Adjust the zoom to reduce or enlarge the image. page 6-20
Density Adjust density. page 6-15
Duplex Produces two-sided copies. You can also create single-sided copies from two-sided
originals.
page 6-24
Combine Combines 2 or 4 original sheets into 1 printed page. page 6-22
Quiet Mode Lower print and scan speed for quiet processing. page 6-27
Functions Description
Reference
page
Collate/Offset Offsets the output by page or set. page 6-13
ID Card Copy Use this when you want to copy a driver's license or an insurance card. When you
scan the front and back of the card, both sides will be combined and copied onto a
single sheet.
page 6-10
Original Size Specify the original size to be scanned. page 6-10
Original Orientation Select the orientation of the original document top edge to scan correct direction. page 6-12
Mixed Size Originals Scans all sheets in the document processor, even if they are of different sizes. page 6-13
Paper Output Specify the output tray. page 6-14
Staple Staples the finished documents. The staple position can be selected. page 6-14
Original Image Select original image type for best results. page 6-16
EcoPrint EcoPrint saves toner when printing. page 6-17
Sharpness Adjusts the sharpness of image outlines. page 6-18
Contrast You can adjust the contrast between light and dark areas of the image. page 6-18
Background Density
Adj.
Removes dark background from originals, such as newspapers. page 6-19
Ready to copy.
Functions
Original Size
A4
Close
10:10
Original Orientation
Top Edge on Top
Collate
Off
ID Card Copy
Collate/Offset
1/4
Add/Edit
Shortcut
Ready to copy.
Copy Copies
Paper
Selection
Zoom Density
Duplex Combine
1-sided>>1-sided
A4 100% Normal 0
Off
Functions
10:10
Favorites
Quiet
Mode
Off
ID Card Copy
Function
key

Kyocera ECOSYS M3860idn Specifications

General

N-up printing	2, 4, 6, 8, 9, 16, 25
Barcode printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Print margin top (min)	4 mm
Time to first page (black, normal)	4.5 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Duplex print speed (black, normal quality, A4/US Letter)	43 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6 s
Copy speed (black, normal quality, A4)	60 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	216 x 915 mm
Scan speed (color)	40 ppm
Image formats supported	JPEG, MMR, TIFF
Duplex scan speed (black)	120 ppm
Duplex scan speed (color)	80 ppm
Document formats supported	PDF, XPS
Optical scanning resolution (black)	600 x 600 ppi
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Ink tank system	No
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 20000 pages per month
Replacement cartridges	TK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, OpenXPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, TIFF
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1276 W
Power consumption (off)	0.09 W
Power consumption (ready)	24 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	798 W
Power consumption (printing)	723 W
Power consumption (average operating)	773 W
Energy Star Typical Electricity Consumption (TEC)	3 kWh/week
Processor cores	2
Processor family	ARM Cortex-A9
Coprocessor frequency	0.1 GHz
Card reader integrated	-
Compatible memory cards	SD, SDHC
Maximum internal memory	3072 MB
Sound power level (standby)	23.5 dB
Sound pressure level (printing)	55.5 dB
Certification	TÜV/GS, CE
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Email protocols	POP3, SMTP
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Paper input type	Cassette
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
Scan media weight	50 - 120 g/m²
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Envelopes, Legal, Letter, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, RoHS, EPEAT Silver, ENERGY STAR
Cables included	AC
Included cartridge capacity (black)	11000 pages
Package depth	570 mm
Package width	633 mm
Package height	730 mm
Package weight	32000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	495 mm
Width	480 mm
Height	613 mm
