Kyocera ECOSYS M3860idn - With Optional Equipments Attached

To Next Page

To Previous Page

2-10

Installing and Setting up the Machine > Part Names

With Optional Equipments Attached

Model without the finisher

1 Card Reader

2 Cassette 2

3 Cassette 3

4 Cassette 4

5 Cassette 5

6 Castor kit

7 Manual Stapler

8 Rear Tray

9 Paper Stopper

Optional Equipment (page 11-2)
