8-28
Setup and Registration (System Menu) > System Menu
System/Network
Configures machine system settings.
Network
[System Menu/Counter] key > [System/Network] > [Network]
Configures network settings.
Host Name
Wi-Fi Direct Settings
Set Wi-Fi Direct.
Wi-Fi Settings
Set Wi-Fi.
Item Description
Host Name
Check the host name of the machine. Host name can be changed from Command Center RX.
Changing Device Information (page 2-62)
NOTE
This function is displayed when the optional Wireless Network Interface Kit is installed.
Item Description
Wi-Fi Direct Select whether to use Wi-Fi Direct.
Value: Off, On
Device Name Specify the device name.
NOTE
Up to 32 characters can be entered.
This function is displayed when [Wi-Fi Direct] is set to [On].
IP Address Check the IP address of the machine.
TCP/IP Setting (page 8-30)
NOTE
This function is displayed when [Wi-Fi Direct] is set to [On].
Auto Disconnect Automatically disconnect devices connected through Wi-Fi Direct.
Value: Off, On
NOTE
If you select [ON], set the waiting time for automatic disconnection.
This function is displayed when [Wi-Fi Direct] is set to [On].
NOTE
This function is displayed when the optional Wireless Network Interface Kit is installed.
Item Description
Wi-Fi Select whether to use Wi-Fi.
Value:
Off, On
