Kyocera ECOSYS P3050dn

2T6/2T7/2T8/2T9
2-3-5
YC32 33 GND - - Ground
Connected to
the engine
PWB
34 GND - - Ground
35 GND - - Ground
36 GND - - Ground
37 GND - - Ground
38 GND - - Ground
39 LVU_SLEEP_
N
O DC0V/3.3V LVU energy-saving control signal
40 POWER_SW I DC0V/3.3V PowerSW
41 E2C_IRN I DC0V/3.3V G6 interrupt signal
42 E2C_WKUP_
BGD_N
I DC0V/3.3V Engine BGM return trigger
43 ENG_HLDN O DC0V/3.3V Engine Hold signal
44 C2E_QUICK_
START
O DC0V/3.3V Speed priority return notification signal
45 PVSYNC I DC0V/3.3V VSYNC
46 GND - - Ground
47 P2C_WKUP_
RDY
I DC0V/3.3V Ready return trigger signal
48 ENERGYSAV
ERKEY_N
I DC0V/3.3V Key input
49 C2P_RST_N O DC0V/3.3V Panel reset signal
50 P2C_SDAT I DC0V/3.3V Panel received data sjgnal
51 C2P_SDAT O DC0V/3.3V Panel transmitted data signal
52 GND - - Ground
53 SDIF_SDCD I DC0V/3.3V Card detect signal
54 SDIF_INTA I DC0V/3.3V Interrupt signal
55 SDIF_CMD I/O DC0V/3.3V Command signal
56 BDN_D I DC0V/3.3V BD signal
57 SH2D O DC0V/3.3V Sample hold signal
58 GND - - Ground
59 LDOUT_2_DN O LVDS Video signal
60 LDOUT_2_DP O LVDS Video signal
Connector Pin Signal I/O Voltage Description
