2T6/2T7/2T8/2T9
1-2-7
1. Pull the cassette from the printer out.
(45 ppm model only)
2. Push the bottom plate down.
Figure 1-2-10
(Common)
3. Turn the cassette size dial so that the
size of the paper you are going to use
appears in the cassette size window.
Figure 1-2-11
4. Push the lock lever on the left side
guide and slide to the desired paper
size.
Figure 1-2-12
(45 ppm model only)
Botom plate
Cassette
Cassette size dial
Cassette size window
Paper width guide
Paper width guide
Lock lever
To Next Page
