Kyocera ECOSYS P3050dn

2T6/2T7/2T8/2T9
2-3-17
Connector Pin Signal I/O Voltage Description
YC1 1 EECLK I 0/3.3 V DC(pulse) Clock signal
Connected to
the engine
PWB
2 GND - - Ground
3 EESIO I/O 0/3.3 V DC Data signal
4 ERASER I 0/3.3 V DC CL control signal
5 +3.3V3_F2 I 3.3 V DC 3.3 V DC power input from EPWB
6 TSENS O Analog TS output signal
7 SBMDIR I 0/5 V DC SBM: On/Off
8 WTSENS O Analog WTS output signal
9 SBMENBLN I 0/3.3 V DC SBM output control signal
10 WTLED I 0/3.3 V DC Waste toner LED control
11 SBMSTEP I 0/3.3 V DC SBM step signal
12 MEFSENS O 0/3.3 V DC MPS: On/Off
13 SBMMODE I 0/3.3 V DC SBM mode control signal
14 +3.3V1_PWM
_F2
I 3.3 V DC 3.3 V DC power input from EPWB
15 TMOT I 0/3.3 V DC TM: On/Off
16 LFANN I 0/24 V DC LFM: On/Off
17 FUDR I 0/24 V DC FSSOL: On/Off
18 ENVMOT I 0/5 V DC ENVM: On/Off
19 FDDR I 0/24 V DC FSSOL: On/Off
20 DUJAMSEN1
N
O 0/3.3 V DC DUS1: On/Off
21 REGSEN2 O 0/3.3 V DC RS2: On/ Off
22 REARSWN O 0/3.3 V DC RECSW: On/Off
YC2 1 1WIRE - - -
Connected to
the engine
PWB
2 +24V3_IL_F5 I 24 V DC 24 V DC power input from EPWB
3 GND - Ground
4 GND - Ground
5 +24V0_F3 I 24 V DC 24 V DC power input from EPWB
YC3 1 TSENS I Analog TS output signal
Connected to
the drum
connect
PWB
2 +24V6 O 24 V DC 24 V DC power output to DRRPWB
3 ERASERN O 0/24 V DC CL: On/Off
4 EECLK O 0/24 V DC(pulse) Clock signal
5 EESIO I/O 0/3.3 V DC Data signal
6 TMOT O 0/5 V DC TM control signal
7 +3.3V6 O 3.3 V DC 3.3 V DC power output to DRRPWB
8 GND - - Ground
9 REGSEN2 I 0/3.3 V DC RS2: On/Off
