Kyocera ECOSYS P3050dn

3NY
2-3-3
YC6 1 TMDIR O 0/3.3 V DC PFPFM rotation direction signal
Connected to
the PF paper
feed motor
2 TMLOCK I 0/3.3 V DC PFPFM rotation stable signal
3 TMCLK O 0/3.3 V DC(pulse) PFPFM clock signal
4 TMDRVN O 0/3.3 V DC PFPFM control signal
5 GND - - Ground
6 +24V2 - 24 V DC 24 V DC power output to PFPFM
YC7 1 GND - - Ground
Connected to
the PF lift
motor
2 LMOTOR O 0/3.3 V DC PFLM control signal
YC8 1 +24V2 - 24 V DC 24 V DC power output to PFFCL
Connected to
the PF paper
feed clutch
and PF feed
clutch
2 FEEDCLN O 0/3.3 V DC PFFCL control signal
3 +24V2 - 24 V DC 24 V DC power output to PFPFCL
4 TRANSCLN O 0/3.3 V DC PFPFCL control signal
Connector Pin Signal I/O Voltage Description
