2PR
1-5-43
6. Remove two screws.
7. Draw the wires into the printer inside.
8. Hold the handle and then remove the laser
scanner unit.
9. Check or replace the laser scanner unit and
refit all the removed parts.
Figure 1-5-61
Laser scanner unit
Handle
Screw
Screw
Wires
