Figure 2-1-16 Transfer/separation section block diagram
Separation needle bias output
VOSL
VOPL
LEDREFL
VOSR
VOPR
LEDREFR
YC5-5
YC5-4
YC5-2
YC6-5
YC6-4
YC6-2
CLCNT
YC600-33
8
T1YCNT
YC600-34
7
T1CCNT
YC600-35
6
T1MCNT
YC600-36
5
T1KCNT
YC610-2
2
T2CNT
YC610-3
3
T2REM
YC610-4
4
SSEL
YC610-5
5
SREM
YC610-6
6
Engine PWB
High voltage
PWB 1
High voltage
PWB 2
Left
ID sensor
Right
ID sensor
Separation
needle
Secondary
transfer roller
Primary
transfer
roller M
Primary
transfer
roller C
Primary
transfer
roller Y
Primary
transfer
roller K
Transfer belt
Cleaning
roller
Secondary transfer bias output
Primary transfer bias output K
Primary transfer bias output Y
Primary transfer bias output C
Primary transfer
bias output M
Cleaning bias output
