Kyocera ECOSYS P7035cdn Service Manual

2PR
2-3-5
YC26 1 DLPCLDRN O 0/24 V DC Developing clutch K: On/Off
Connected
to the devel-
oping clutch
K, develop-
ing motor K,
Registration
clutch and
paper feed
clutch
2 +24V3 O 24 V DC 24 V DC power source
3 MOTKREV O 0/3.3 V DC Developing motor K drive switch signal
4
DLPMOTKRDYN I 0/3.3 V DC Developing motor K ready signal
5 SPEEDSEL O 0/3.3 V DC Developing motor K speed selection signal
6 DLPMOTKCLK O 0/3.3 V DC (pulse) Developing motor K clock signal
7 DLPMOTKREN O 0/3.3 V DC Developing motor K: On/Off
8 GND - - Ground
9 +24V3 O 24 V DC 24 V DC power source
10 REGCLDRN O 0/24 V DC Registration clutch: On/Off
11 +24V3 O 24 V DC 24 V DC power source
12 FEDCLDRN O 0/24 V DC Paper feed clutch: On/Off
13 +24V3 O 24 V DC 24 V DC power source
YC27 1 MOTREV O 0/3.3 V DC Developing motor MCY drive switch signal
Connected
to the devel-
oping motor
MCY
2 DLPMOTRDYN I 0/3.3 V DC Developing motor MCY ready signal
3 SPEEDSEL O 0/3.3 V DC Developing motor MCY speed switch signal
4 DLPMOTCLK O 0/3.3 V DC (pulse) Developing motor MCY clock signal
5 DLPMOTREN O 0/3.3 V DC Developing motor MCY: On/Off
6 GND - - Ground
7 +24V3 O 24 V DC 24 V DC power source
YC28 1 LMOTDRN O 0/24 V DC Lift motor: On/Off
Connected
to the lift
motor
2 GND - - Ground
YC31 A1 VDOMP I LVDS APC PWB M video data signal (+)
Connected
to the main
PWB
A2 VDOMN I LVDS APC PWB M video data signal (-)
A3 VDOYP I LVDS APC PWB Y video data signal (+)
A4 VDOYN I LVDS APC PWB Y video data signal (-)
A5 GND - - Ground
A6 PDMN O 0/3.3 V DC (pulse) Horizontal synchronization signal
A7 PDYN O 0/3.3 V DC (pulse) Horizontal synchronization signal
A8 GND - - Ground
A9 FPRXD I 0/3.3 V DC Operation panel PWB comunication recive
exchange data signal
A10 FPTXD I 0/3.3 V DC Operation panel PWB communication trnsmit
exchange data signal
A11 FPRSTN I 0/3.3 V DC Operation panel PWB reset signal
A12 +3.3V1 O 3.3 V DC 3.3 V DC power source
A13 SO O 0/3.3 V DC (pulse) Main PWB serial communication data signal
A14 SDIR O 0/3.3 V DC Main PWB communication direction signal
A15 EGIRN O 0/3.3 V DC Engine interrupt signal
A16 +5V1 O 5 V DC 5 V DC power source
A17 +5V1 O 5 V DC 5 V DC power source
A18 GND - - Ground
A19 GND - - Ground
A20 +24V1 O 24 V DC 24 V DC power source
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
