Kyocera ECOSYS P7035cdn Service Manual

2PR
2-3-6
YC31 B1 VDOCP I LVDS APC PWB C video data signal (+)
Connected
to the main
PWB
B2 VDOCN I LVDS APC PWB C video data signal (-)
B3 VDOCP I LVDS APC PWB K video data signal (+)
B4 VDOCN I LVDS APC PWB K video data signal (-)
B5 GND - - Ground
B6 PDMN O 0/3.3 V DC (pulse) Horizontal synchronization signal
B7 PDYN O 0/3.3 V DC (pulse) Horizontal synchronization signal
B8 GND - - Ground
B9 WAKEUP_PNL
KEY
O 0/3.3 V DC Pannel wakeup signal
B10 FPRTS I 0/3.3 V DC (pulse) Operation panel comunication recive signal
B11 ST_WUP I 0/3.3 V DC Warmup signal
B12 +3.3V1 O 3.3 V DC 3.3 V DC power source
B13 SI O 0/3.3 V DC (pulse) Main PWB serial communication data signal
B14 SCLN O 0/3.3 V DC (pulse) Main PWB clock signal
B15 SBSY O 0/3.3 V DC Main PWB busy signal
B16 VSYNC O 0/3.3 V DC PD mask control signal
B17 EEDAT I/O 0/3.3 V DC (pulse) EEPROM data signal
B18 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
B19 GND - - Ground
B20 GND - - Ground
YC33 1 GND - - Ground
Connected
to the option
paper feeder
2 OPSCLK O 0/5 V DC (pulse) Paper feeder clock signal
3 OPRDYN I 0/5 V DC Paper feeder ready signal
4 OPSDI I 0/5 V DC (pulse) Paper feeder serial communication data signal
5 OPSDO O 0/5 V DC (pulse) Paper feeder serial communication data signal
6 OP5V O 5 V DC 5 V DC power source
7 GND - - Ground
8 OPSEL0 O 0/5 V DC Paper feeder selection signal
9 OPSEL1 O 0/5 V DC Paper feeder selection signal
10 OPSEL2 O 0/5 V DC Paper feeder selection signal
11 OP24 O 24 V DC 24 V DC power source
YC34 1 ERASEMDR O 0/24 V DC Eraser lamp M: On/Off
Connected
to the drum
relay PWB
2 TNSENM I Analog Toner sensor M detection voltage
3 ERASECDR O 0/24 V DC Eraser lamp C: On/Off
4 TNSENC I Analog Toner sensor C detection voltage
5 ERASEYDR O 0/24 V DC Eraser lamp Y: On/Off
6 TNSENY I Analog Toner sensor Y detection voltage
7EECLK O
0/3.3 V DC (pulse)
EEPROM clock signal
8 GND - - Ground
9EEDATA I/O
0/3.3 V DC (pulse)
EEPROM data signal
10 +3.3V1 O 3.3 V DC 3.3 V DC power source
11 ERASEKDR O 0/24 V DC Eraser lamp K: On/Off
12 +3.3V2 O 3.3 V DC 3.3 V DC power source
13 TNSENK I Analog Toner sensor K detection voltage
14 DLPTHERM I Analog Developing thermistor detection voltage
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
