Kyocera ECOSYS P7035cdn Service Manual

2PR
2-3-9
YC606 1 +5V3 O 5 V DC 5 V DC power source
Connected
to the APC
PWB M/C
2 LONBMN O 0/3.3 V DC APC PWB M sample/hold signal
3 ENBMN O 0/3.3 V DC APC PWB M laser enable signal
4 VDOMP O LVDS APC PWB M video data signal (+)
5 VDOMN O LVDS APC PWB M video data signal (-)
6 GND - - Ground
7 VREFM O Analog APC PWB M control signal
8 +5V3 O 5 V DC 5 V DC power source
9 LONBCN I 0/3.3 V DC (pulse) APC PWB C sample/hold signal
10 ENBCN O 3.3 V DC APC PWB C laser enable signal
11 VDOCP O 0/3.3 V DC APC PWB C video data signal (+)
12 VDOCN O 0/3.3 V DC APC PWB C video data signal (-)
13 GND - - Ground
14 VREFC O Analog APC PWB C laser power reference voltage
YC607 1 +5V3 O 5 V DC 5 V DC power source
Connected
to the APC
PWB Y/K
2 LONBYN O 0/3.3 V DC APC PWB Y sample/hold signal
3 ENBYN O 0/3.3 V DC APC PWB Y laser enable signal
4 VDOYP O LVDS APC PWB Y video data signal (+)
5 VDOYN O LVDS APC PWB Y video data signal (-)
6 GND - - Ground
7 VREFY O Analog APC PWB Y laser power reference voltage
8- -- -
9 PDYN I 0/3.3 V DC (pulse) Horizontal synchronization signal
10 +3.3V3 O 3.3 V DC 3.3 V DC power source
11 +5V3 O 5 V DC 5 V DC power source
12 LONBKN O 0/3.3 V DC APC PWB K sample/hold signal
13 ENBKN O 0/3.3 V DC APC PWB K laser enable signal
14 VDOKP O LVDS APC PWB K video data signal (+)
15 VDOKN O LVDS APC PWB K video data signal (-)
16 GND - - Ground
17 VREFK O Analog APC PWB K laser power reference voltage
18 THERM2 - - Not used
19 PDMN I 0/3.3 V DC (pulse) Horizontal synchronization signal
20 +3.3V3 O 3.3 V DC 3.3 V DC power source
YC608 A1
DRUMMOTYRDYN I 0/3.3 V DC Drum motor Y ready signal
Connected
to the drum
motor Y/K/
M/C
A2 SPEEDSEL O 0/3.3 V DC Drum motor Y speed change signal
A3 DRUMMOTCLK O
0/3.3 V DC (pulse)
Drum motor Y clock signal
A4
DRUMMOTYREN O 0/3.3 V DC Drum motor Y: On/Off
A5 GND - - Ground
A6 +24V3 O 24 V DC 24 V DC power source
A7 DRUMMOTKRDYN I 0/3.3 V DC Drum motor K ready signal
A8 SPEEDSEL O 0/3.3 V DC Drum motor K speed change signal
A9 DRUMMOTCLK O
0/3.3 V DC (pulse)
Drum motor K clock signal
A10
DRUMMOTKREN O 0/3.3 V DC Drum motor K: On/Off
A11 GND - - Ground
A12 +24V3 O 24 V DC 24 V DC power source
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
