Kyocera ECOSYS P7035cdn Service Manual

2PR
2-3-10
YC608 B1 DRUMMOTMRDYN I 0/3.3 V DC Drum motor M ready signal
Connected
to the drum
motor Y/K/
M/C
B2 SPEEDSEL O 0/3.3 V DC Drum motor M speed change signal
B3 DRUMMOTCLK O
0/3.3 V DC (pulse)
Drum motor M clock signal
B4
DRUMMOTMREN O 0/3.3 V DC Drum motor M: On/Off
B5 GND - - Ground
B6 +24V3 O 24 V DC 24 V DC power source
B7 DRUMMOTCRDYN
I
0/3.3 V DC Drum motor C ready signal
B8 SPEEDSEL O 0/3.3 V DC Drum motor C speed change signal
B9 DRUMMOTCLK O
0/3.3 V DC (pulse)
Drum motor C clock signal
B10
DRUMMOTCREN O 0/3.3 V DC Drum motor C: On/Off
B11 GND - - Ground
B12 +24V3 O 24 V DC 24 V DC power source
YC609 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the left
side fan
motor
2 LSIDEDRN O 0/12/24 V DC Left side fan motor: Full speed/Half speed/Off
YC610 1 GND - - Ground
Connected
to the high
voltage
PWB 2
2 T1KCNT O 0/24 V DC Primary transfer bias control signal (Black)
3 T2CNT O 0/24 V DC Secondary transfer bias control signal
4 T2RREM O 0/24 V DC Secondary transfer bias (reverse) control signal
5 SSEL O 0/24 V DC Separation needle bias output change signal
6 SREM O 0/24 V DC Separation needle bias: On/Off
7 +24V4 O 24 V DC 24 V DC power source
YC613 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the LSU
fan motor
2 LSUFANDRN O 0/12/24 V DC LSU fan motor: Full speed/Half speed/Off
YC615 1 ENVEMOTA O 24/0 V DC Fuser pressure change motor: Fwd/Stop/(Rev)
Connected
to the fuser
pressure
change
motor
2 ENVEMOTB O 24/0 V DC Fuser pressure change motor: Rev/Stop/(Fwd)
YC616 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the fuser
fan motor 2
2 SUBFANDRN O 0/12/24 V DC Fuser fan motor 2: Full speed/Half speed/Off
YC617 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the ID
solenoid
2 IDSOLDRN O 0/24 V DC ID solenoid: On/Off
YC618 1 +24V1 O 24 V DC 24 V DC power source
Connected
to the devel-
oping fan
motor 2
2 DLPFANDRN O 0/12/24 V DC Developing fan motor 2: Full speed/Half speed/Off
YC619 1 DLPEEDAT I/O 0/3.3 V DC Developing PWB EEPROM data signal
Connected
to the drum
relay PWB
2 DLPEECLK O 0/3.3 V DC (pulse) Developing PWB EEPROM clock signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
