Kyocera ECOSYS P7035cdn - Printer Machine Parts

2PR
1-2-3
120 V AC model
Figure 1-2-3 120 V AC model
2
9
3
4
11
6
7
5
10
1
19
19
19
19
12
23
22
15
14
18
13
20
21
21
17
16
8
1. Printer
2. Outer case
3. Bottom sheet
4. Bottom pad FL
5. Bottom pad FR
6. Bottom pad BL
7. Bottom pad BR
8. Main pad
9. Upper tray US
10. Machine cover 600  600  900
11. Machine cover
12. Cassette cushion US
13. Left upper pad
14. Right upper pad
15. Toner container (Black)
16. Toner container (Yellow)
17. Toner container (Cyan)
18. Toner container (Magenta)
19. Plastic bags 200  700
20. Power cord
21. Waste toner boxes
22. Documents etc.
