2PR
1-2-7
1-2-5 Installing the SSD disk
<Procedure>
1. Turn off printer power switch.
Caution: Do not insert or remove SSD unit
while printer power is on.
Doing so may cause damage to the printer
and the SSD.
2. Remove two screws and then remove the
option interface slot cover.
3. Insert the SSD into the option interface slot.
Push it in all the way.
4. Secure the SSD by using two screws.
Figure 1-2-10
SSD
Option
interface slot
Option interface
slot cover
Screw
Screw
To Next Page
