Kyocera ECOSYS PA2100cx User Manual

4-17
Printing from PC > Monitoring the Printer Status (Status Monitor)
Monitoring the Printer Status (Status
Monitor)
The Status Monitor monitors the machine status and provides an ongoing reporting function.
Accessing the Status Monitor
The Status Monitor also starts up when printing is started.
Exiting the Status Monitor
Use either of the methods listed below to exit the Status Monitor.
• Exit manually:
Click the settings icon and select Exit in the menu to exit the Status Monitor.
• Exit automatically:
The Status Monitor automatically shuts down after 7 minutes if it is not being used.
Quick View State
The status of the machine is displayed using icons. Detailed information is displayed when the Expand button is clicked.
Detailed information is displayed by clicking on each icon tab.
NOTE
When you activate Status Monitor, check the status below.
• KX DRIVER is installed.
• Either [Enhanced_WSD] or [Enhanced WSD(SSL)] is enabled.
Network Settings (page 6-13)
1 Printing progress tab
2 Paper tray status tab
3 Toner status tab
4 Alert tab
5 Expand button
6 Settings icon
1 2
3
4
5
6

Kyocera ECOSYS PA2100cx Specifications

General

Color	Yes
N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Booklet printing function	No
Time to first page (black, normal)	11 s
Time to first page (color, normal)	12.5 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	21 ppm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	33 W
Power consumption (printing)	345 W
Power consumption (PowerSave)	0.9 W
Energy Star Typical Electricity Consumption (TEC)	0.691 kWh/week
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	65000 pages per month
Recommended duty cycle	500 - 1500 pages per month
Replacement cartridges	TK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges	4
Page description languages	PDF, PCL 6, XPS, PostScript 3
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
USB connector	USB Type-A
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor family	ARM Cortex
Sound power level (standby)	30 dB
Sound pressure level (printing)	48 dB
Display	LCD
Control type	Buttons
Certification	GS, TUV
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Sustainability certificates	CE
Package depth	567 mm
Package width	592 mm
Package height	460 mm
Package weight	27000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Width	410 mm
Height	329 mm
