2-3

Installing and Setting up the Machine > Part Names (Connectors/Interior)

Part Names (Connectors/Interior)

1 USB Interface Connector

2 Network Interface Connector

3 Feed Cover

4 Paper Length Guide

5 Paper Width Guides

6 Multipurpose Tray

7 Tray Extension

8 Paper Width Guides

9 Fuser Cover

6 7
