Page #48 background imageLoading...
Page #48 background image
2-19
Installing and Setting up the Machine > Network Setup
Configuring the Wireless Network
Setting the Connection by Using the Wi-Fi Setup Tool
To send the Wi-Fi settings configured in the Wi-Fi Setup Tool to the machine, connect the computer or handheld device
with the machine locally. The connection methods are wired connection via LAN cable and wireless LAN connection
(Wi-Fi Direct).
Wired Connection by Using LAN Cable
1
Connect the machine with a computer
1 Connect the machine with a computer via LAN cable when the machine is powered on.
2 Turn on the computer.
IP address (link local address) of the machine and computer is generated automatically.
When the wireless network function is available on the machine and the connection settings are configured, it is possible
to print in a wireless network (wireless LAN) environment. The configuration methods are as follows:
Configuration Method Description Reference Page
Configuring the Connection
from the Operation Panel on
This Machine
Use Wi-Fi Settings or Wireless Network to configure the
network in details from System menu.
Wi-Fi Settings (page 6-10)
Setting the Connection by
Using the Wi-Fi Setup Tool
This is the tool included in the Product Library. You can
configure the connection according to the instructions
provided by the wizard.
Setting the Connection by Using
the Wi-Fi Setup Tool (page 2-19)
Configuring Connections on
the Web Page
The connection can be set from the Command Center RX. Command Center RX User
Guide
NOTE
On a model with a Wi-Fi function, change the settings in "Communication" appropriately if you switch to other than a
wired network interface.
Communication (page 6-13)
NOTE
Before using the Wi-Fi Setup Tool, connect your computer to this machine locally with wired LAN cable or Wi-Fi
Direct.
To use Wi-Fi Direct, confirm that the Wi-Fi Direct is enabled (Wi-Fi Direct is set to [On]) and Restart Network from
the operation panel, before your computer will be connected to this machine with Wi-Fi Direct.
To use a wired LAN cable directly connected to the machine, the Auto-IP (Link-local) address will be assigned to the
machine and the computer. This machine applies Auto-IP as the default settings.
Configure the settings on the operation panel if your computer supports WPS.
Wi-Fi Settings
(page 6-10)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS PA2100cx and is the answer not in the manual?

Kyocera ECOSYS PA2100cx Specifications

General IconGeneral
ColorYes
N-up printing2, 4, 6, 8, 9, 16, 25
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Booklet printing functionNo
Time to first page (black, normal)11 s
Time to first page (color, normal)12.5 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)21 ppm
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.2 W
Power consumption (ready)33 W
Power consumption (printing)345 W
Power consumption (PowerSave)0.9 W
Energy Star Typical Electricity Consumption (TEC)0.691 kWh/week
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originChina
Maximum duty cycle65000 pages per month
Recommended duty cycle500 - 1500 pages per month
Replacement cartridgesTK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges4
Page description languagesPDF, PCL 6, XPS, PostScript 3
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity550 sheets
Paper tray 1 input capacity250 sheets
Total number of input trays2
Maximum number of input trays3
Multi-Purpose tray input capacity50 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesLegal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
USB connectorUSB Type-A
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity1
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor familyARM Cortex
Sound power level (standby)30 dB
Sound pressure level (printing)48 dB
DisplayLCD
Control typeButtons
CertificationGS, TUV
Product colorBlack, White
Market positioningHome & office
Display number of lines2 lines
Sustainability certificatesCE
Package depth567 mm
Package width592 mm
Package height460 mm
Package weight27000 g
Cables includedAC
Included cartridge capacity (black)1500 pages
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Width410 mm
Height329 mm
