Kyocera ECOSYS PA2100cx User Manual

6-3
Setup and Registration (System Menu) > System Menu
Menu Settings
This section explains the functions that can be configured in Menu. To configure the settings, select the item in System
Menu and select the setting item. For details on each function, see the table below.
Item Description Reference Page
Print Report Print reports to check the machine settings and status. page 6-4
Counter Check the number of sheets printed. page 2-43
Paper Settings Configure settings for paper. page 6-6
Print Settings Configure settings for printing. page 6-8
Wi-Fi Direct Set Set Wi-Fi Direct. page 6-10
Wi-Fi Settings Set Wi-Fi. page 6-10
Wired Network Configure wired network settings. page 6-12
Network Settings Configure network settings. page 6-13
Message Language Select the language displayed on the message display. page 6-17
Date Setting Configure settings related to the date and time. page 6-17
Buzzer Set options for buzzer sound during the machine operations. page 6-18
RAM Disk Mode A RAM disk can be created and its size can be set. page 6-18
SD Card Format an SD/SDHC memory card. page 6-18
Error Handling Select whether to cancel or continue the job when error has occurred. page 6-19
ColorToner Empty Select whether printing is prohibited or the Print in Black and White
setting is used for printing once the color toner runs out.
page 6-19
Timer Configure settings related to the time. page 6-19
Sleep Level Set. Select the Sleep level. page 6-20
Power Off Rule (models for
Europe)
Select whether or not the machine enters Power Off mode. page 6-20
Power Off Timer (models for
Europe)
Select whether to turn off the power automatically after a period of
inactivity.
page 6-21
Disp. Status/Log Set the display method of the Status/Log. page 6-21
Low Toner Alert Set the amount of remaining toner to notify the administrator when to
order a toner when the toner is running low.
page 6-21
Security The security functions can be set up to protect printer operation and the
print data.
page 6-22
I/F Block This allows you to protect this machine by blocking the interface with
external devices such as USB hosts.
page 6-22
Security Level The Security Level setting is primarily a menu option used by service
personnel for maintenance work. There is no need for customers to use
this menu.
—
User/Job Account Configures settings related to machine management.
User Login:
Overview of User Login Administration (page 7-2)
Job Accounting:
Overview of Job Accounting (page 7-6)
—

Kyocera ECOSYS PA2100cx Specifications

General

Color	Yes
N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Booklet printing function	No
Time to first page (black, normal)	11 s
Time to first page (color, normal)	12.5 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	21 ppm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	33 W
Power consumption (printing)	345 W
Power consumption (PowerSave)	0.9 W
Energy Star Typical Electricity Consumption (TEC)	0.691 kWh/week
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	65000 pages per month
Recommended duty cycle	500 - 1500 pages per month
Replacement cartridges	TK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges	4
Page description languages	PDF, PCL 6, XPS, PostScript 3
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
USB connector	USB Type-A
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor family	ARM Cortex
Sound power level (standby)	30 dB
Sound pressure level (printing)	48 dB
Display	LCD
Control type	Buttons
Certification	GS, TUV
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Sustainability certificates	CE
Package depth	567 mm
Package width	592 mm
Package height	460 mm
Package weight	27000 g
Cables included	AC
Included cartridge capacity (black)	1500 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Width	410 mm
Height	329 mm
