7-15
User Authentication and Accounting (User Login, Job Accounting) > Job Accounting (Local)
Job Accounting for Printing
The number of jobs to be printed from the computer can be managed by Job Accounting.
Setting Printer Driver
To manage the number of jobs to be printed from the PC on the network, you need configure the following settings by
using the printer driver on the PC. Instructions are based on interface elements as they appear in Windows 10.
1
Display the screen.
1 Click [Start] button on the Windows, and then select [Windows System], [Control Panel],
and [View devices and printers].
2 Right-click the printer driver icon of the machine, and click the [Printer properties] menu of
the printer driver.
3 Click [Administrator] on the [Device Settings] tab.
2
Configure the settings.
1 Select [Job accounting] on the [Job Accounting] tab.
2 Set the Account ID.
[Use specific account ID]:
Enter the Account ID. Printing will be performed using the entered
Account ID. If this option is selected, the user does not have to enter the Account ID for each print job.
[Prompt for account ID]: A screen for entering the Account ID will be displayed when attempting a
printing. The Account ID must be entered each time a printing is attempted.
[Prompt for account ID and validate]: A screen for entering the Account ID will be displayed when
attempting a printing. The Account ID stored in the Account ID list needs to be entered. The Account
ID must be entered each time a printing is attempted.
[Display account ID list]: The Account ID list is displayed when printing. The Account ID to be used
needs to be selected from the list.
[Validate user name (computer) or prompt for account ID]: When printing, the Windows user
name is searched in the "Login user names" and printing is possible if the name is registered. If the
name is not registered, the printing will be canceled for users with only user authority. If the user has
administrator privileges, the screen to enter the user name and password will appear.
NOTE
In Windows 8.1, select [Settings] in charms on Desktop, and select [Control Panel],
and then [Devices and Printers].
1
2

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS PA2100cx and is the answer not in the manual?

Kyocera ECOSYS PA2100cx Specifications

General IconGeneral
ColorYes
N-up printing2, 4, 6, 8, 9, 16, 25
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Booklet printing functionNo
Time to first page (black, normal)11 s
Time to first page (color, normal)12.5 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)21 ppm
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.2 W
Power consumption (ready)33 W
Power consumption (printing)345 W
Power consumption (PowerSave)0.9 W
Energy Star Typical Electricity Consumption (TEC)0.691 kWh/week
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originChina
Maximum duty cycle65000 pages per month
Recommended duty cycle500 - 1500 pages per month
Replacement cartridgesTK-5430K Zwart (toner 1.250) ISO/IEC 19798 TK-5430Y Geel (toner 1.250) ISO/IEC 19798 TK-5430M Magenta (toner 1.250) ISO/IEC 19798 TK-5430C Cyaan (toner 1.250) ISO/IEC 19798 TK-5440K Zwart (toner 2.800) ISO/IEC 19798 TK-5440Y Geel (toner 2.400) ISO/IEC 19798 TK-5440M Magenta (toner 2.400) ISO/IEC 19798 TK-5440C Cyaan (toner 2.400) ISO/IEC 19798
Number of print cartridges4
Page description languagesPDF, PCL 6, XPS, PostScript 3
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity550 sheets
Paper tray 1 input capacity250 sheets
Total number of input trays2
Maximum number of input trays3
Multi-Purpose tray input capacity50 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesLegal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
USB connectorUSB Type-A
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity1
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor familyARM Cortex
Sound power level (standby)30 dB
Sound pressure level (printing)48 dB
DisplayLCD
Control typeButtons
CertificationGS, TUV
Product colorBlack, White
Market positioningHome & office
Display number of lines2 lines
Sustainability certificatesCE
Package depth567 mm
Package width592 mm
Package height460 mm
Package weight27000 g
Cables includedAC
Included cartridge capacity (black)1500 pages
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Width410 mm
Height329 mm
