Specifications
36 OPERATION GUIDE
Item Description
Memory
- Standard 32MB
- Maximum 288MB
Interfaces
- Parallel
1 (IEEE 1284)
- USB 1 (Full-Speed USB)
- Option IB-11: Serial interface board
IB-21E: Network interface card (10BASE-T/100BASE-TX)
Operating Environment
- Temperature 10 to 32.5°C
- Relative Humidity 20 to 80% RH
- Altitude 2,500m maximum
- Illumination 1,500 lux maximum
Dimensions
(W) × (H) × (D)
378 × 235 × 375mm
14.9 × 9.3 × 14.8"
Weight Approx. 10.5 kg / 23.2 lbs
Operating noise
(in accordance with ISO 7779
[Bystander Position, sound
pressure level at the front])
During printing: LpA = 53dB (A)
During standby: LpA = 28dB (A)
During sleep mode: Immeasurably low
