Kyocera FS-4100DN User Manual

Operation Panel
4-108
4 When the initialization is finished Task is completed. is
displayed. Turn the power switch off and then on.
DataSanitization (Sanitizing the stored data)
This is to completely delete the address information registered on the machine and the stored image data.
1 In the Data Security menu, press U or V to select
DataSanitization.
2 Press [OK]. A confirmation message is displayed.
3 Press [Yes] ([Left Select]). The message Sanitizing the
data. appears and the data sanitization begins.
Pressing [No] ([Right Select]) returns to the Data Security
menu without sanitizing the data.
4 When the data sanitization is finished Complet is displayed. Press
[OK] ([Right Select]) and turn the power switch off.
Task is completed.
Turn the main power
switch off and on.
IMPORTANT To complete this process requires about 30 minutes when an optional SSD (HD-6) is installed and a few
minutes when an SSD (HD-6) is not installed.
You can only performing this operation by logging in with machine administrator privileges.
It is not possible to cancel the process once it has started.
Remove the USB cable and network cable, etc., before performing this operation.
Do not turn off the power supply whilst the deletion is ongoing. If the power switch off during the deletion then the deletion
will automatically be performed when the power is switched back on, but a complete operation cannot be guaranteed.
The data deleted is as listed below.
• Job settings
• Machine settings (Network settings)
• Certificates
• User settings (user list, document boxes)
• Machine administration (job logs, job accounting)
Note It is possible to check the status of data sanitization implementation on the Status page. For details, refer to
Status Page (Printing a printer's status page) on page 4-12.
Note When an optional SSD (HD-6) is installed, the printer
automatically restarts before data sanitization.
Note It is possible to check the result of data sanitization on
the Status page. For details, refer to Status Page (Printing a
printer's status page) on page 4-12.
Sanitize the data.
Are you sure?
* This process will
take a while.
[ Yes ] [ No ]
Sanitizing the data.
Main Memory :Complet
SSD :Complet
[ OK ]

Kyocera FS-4100DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Mobile printing technologies	-
PCL fonts	93
Printer fonts	Bitmap, PCL, PostScript
Maximum duty cycle	200.000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Media thickness	0.11 mm
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
Dimensions (WxDxH)	380 x 416 x 320 mm
