Document Box
5-30
2 Press U or V to select Print and press [OK]. If the selected job was
saved as a Private Print job, its ID is displayed. If the job was saved
in stored job mode, the number of direct copies is displayed.
3 Use the numeric keys to enter the access code entered in the printer
driver.
Press [OK]. If the entered access code is correct, the Copies menu
screen appears.
If the entered access code is incorrect, the ID menu screen
reappears.
4 To print 2 or more copies, use the numeric keys or press U or V to
set the number of copies to be printed.
After selecting the multiple copies in the printer driver, you can also
restore to "1" from the operation panel using the same method.
5 Press [OK]. The message Accepted. appears and the printer prints
the selected job.
Deleting a Private/Stored Job
You can individually delete stored jobs by performing the following procedure. Jobs saved using Private Print will be
automatically deleted when you turn the power off, or after printing, but jobs saved using Stored Job will not be deleted
automatically.
1 In the Job Box menu, press U or V to select Private/Stored.
2 Press [OK]. The Private/Stored screen appears listing the user
names for stored jobs.
3 Press U or V to select the user name you entered in the printer
driver.
Note When the access code is set to the document selected
in the check box,
Incorrect ID is displayed for the
disagreement.
Note --- is displayed first, and it means it according to the set
number of copies when the data of each file is preserved. In this
setting, each set number of copies is printed.
ID:
P
b
*******************
0001
S
Copies:
a
b
(1 - 999,---)
*****
copies
---
Accepted.
Private/Stored:
a
b
********************-
l
User02
l
User03

Table of Contents

Other manuals for Kyocera FS-4300DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-4300DN and is the answer not in the manual?

Kyocera FS-4300DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Print speed (black, normal quality, A4/US Letter)60 ppm
Mobile printing technologiesNot supported
Printing colorsBlack
Maximum duty cycle275000 pages per month
Number of print cartridges1
Page description languagesEpson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model465
Processor familyPowerPC
Compatible memory cardsSD, SDHC
Maximum internal memory1280 MB
Sound power level (standby)27.4 dB
Sound pressure level (printing)56.1 dB
Total input capacity600 sheets
Total output capacity500 sheets
Maximum input capacity2600 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)13.1 W
Power consumption (printing)757 W
Power consumption (PowerSave)1.6 W
DisplayLCD
CertificationTÜV/GS, CE
Product colorBlack, White
Sustainability certificatesBlue Angel, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth416 mm
Width380 mm
Height320 mm
