Kyocera KM-C2525E Service Manual

2JL/2JJ/2JG/2JD
1-5-30
1-5-6 Fuser section
(1) Detaching and refitting the fuser unit
Follow the procedure below to replace the fuser unit.
Procedure
1. Open left cover 1 and paper conveying unit.
2. Remove two screws and remove the fuser
unit.
3. Replace the fuser unit and install the unit.
4. Perform maintenance mode U167 to clear
the counter value (see page 1-3-53).
Figure 1-5-63
Fuser unit
