2JL/2JJ/2JG/2JD
2-3-4
YC10 5 GND - - Ground
Connected
to the main
PWB
6 GND - - Ground
7 +3.3V O 3.3 V DC 3.3 V DC power to the main PWB
8 GND - - Ground
YC11 1 +24V3 I 24 V DC 24 V DC power input (via left cover 1 switch)
Connected
to the
engine PWB
2 FET_SLEEP I 0/3.3 V DC Sleep mode signal: On/Off
3 ZEROC O 0/3.3 V DC
(pulse)
Zero-cross signal
4
FSR_SUBHEAT_DRn
I 0/3.3 V DC Fuser heater 2: On/Off
5
FSR_MAINHEAT_DRn
I 0/3.3 V DC Fuser heater 1: On/Off
6
DRM_HEAT_DRn
- - Not used
7
FSR_PRHEAT_DRn
I 0/3.3 V DC Fuser heater 3: On/Off
8 LVU_FAN I 0/24 V DC Power source fan motor: On/Off
YC13 1 DH_LIVE O 120 V AC 120/220 - 240 V AC power to the cassette heater
Connected
to the cas-
sette heater
220 - 240 V AC
2N.C. -- -
3N.C. -- -
4 DH_COM O 120 V AC 120/220 - 240 V AC power to the cassette heater
220 - 240 V AC
YC14 1 +24V2 O 24 V DC 24 V DC power to the power source fan motor
Connected
to the power
source fan
motor
2 FAN_REM O 24/0 V DC Power source fan motor: On/Off
YC15 1 +24V2 O 24 V DC
24 V DC power to the engine PWB (via left cover switch 1
)
Connected to
the left cover
1 switch and
engine PWB
2 GND - - Ground
YC16 1 SGND - - Ground
Connected
to the
optional
document
finisher
2 SGND - - Ground
3 SGND - - Ground
4 SGND - - Ground
5 SGND - - Ground
6 SGND - - Ground
YC17 1 +24V2 O 24 V DC 24 V DC power to the paper feeder
Connected
to the
optional
paper feeder
and docu-
ment fin-
isher
2 +24V2 O 24 V DC 24 V DC power to the document finisher
3 PGND - - Ground (paper feeder)
4 PGND - - Ground (document finisher)
5 SGND - - Ground (paper feeder)
6 SGND - - Ground (document finisher)
7 +5V2 O 5 V DC 5 V DC power to the paper feeder
8 +5V2 O 5 V DC 5 V DC power to the document finisher
9 N.C. - - Not used
YC18 1 SGND - - Ground
Connected
to the motor
relay PWB
2 +5V2 I 5 V DC 5 V DC power from the motor relay PWB
YC19 1 +5V O 5 V DC 5 V DC power to the FAX relay PWB
Connected
to the FAX
relay PWB
2 GND - - Ground
Connector Pin No. Signal I/O Voltage Description
