Kyocera PF-1100 - Detaching and Reattaching the Left Cover

2RV/2RW/2RX/2RY/3RA
4-22
5. Remove two screws(M3×10TP)(a).
6. Release two hooks (b) of the upper rear
cover(c) and detach it.
Figure 4-33
(1-3)Detaching and reattaching the left cover
Procedures
1. Pull out the cassette
2. Open the front cover (a).
3. Release four hooks (b) at the front side
of the left cover(a).
Figure 4-34
b
a
b
c
b
b
a
