2RV/2RW/2RX/2RY/3RA
2-18
(7-4) Output Status Page
1. Press and hold the [Go] key for three to nine seconds.
*: Output of the service status page by pressing and holding it 10 seconds or more.
Figure 2-8
2. Status page is printed.
(7-5) Completion of installing the main unit (Turning the power off)
1. Check if the [Processing] lamp is turned off and turn the power switch off.
*: It takes approximately 3 minutes for power off.
Figure 2-9
IMPORTANT
While the [Processing] lamp is lit, the main unit is operating. If you turn the power switch off while the main unit is oper-
ating, it may cause malfunctions.
[Go] key
Check that the indicators are off.
To Next Page
