2KR/2KS-1
2-4-4
Section
Maintenance
part/location
User call 500K Points and cautions Page
Optical
section
Laser scanner unit Check
Clean
- Clean the shield glass with a dry cloth. P.1-5-22
Contact glass Clean Clean Clean with alcohol and then a dry cloth.
Slit glass Clean Clean Clean with a dry cloth or alcohol (do not clean
with a wet cloth).
Mirror 1 Clean - Clean with alcohol and then a dry cloth only if
vertical black lines appear on the copy image.
Mirror 2 and mirror 3 Clean - Clean with alcohol and then a dry cloth only if
vertical black lines appear on the copy image.
Lens Clean - Clean with a dry cloth only if vertical black
lines appear on the copy image.
Reflector Clean - Clean with a dry cloth only if vertical black
lines appear on the copy image.
Exposure lamp Check
Replace
- Replace if an image problem occurs. P.1-5-12
Optical rail Grease - Check noise and shifting and then apply
scanner rail grease EM-50L.
Original size sensor Check
Clean
- Clean the sensor emitter and sensor receiver
with alcohol or a dry cloth only if there is a
problem.
Section
Maintenance
part/location
User call 500K Points and cautions Page
Transfer/
separation
sections
Transfer roller unit Clean
Replace
Replace Clean with a cleaning brush or alcohol.
Replace after feeding 500,000 sheets.
P.1-5-29
Section
Maintenance
part/location
User call 500K Points and cautions Page
Developing
section
Developing unit Check
Replace
Replace Replace after feeding 500,000 sheets. P.1-5-28
Section
Maintenance
part/location
User call 500K Points and cautions Page
Drum
section
Drum unit Check
Replace
Replace Replace after feeding 500,000 sheets. P.1-5-25
Main charger unit Clean - Clean with a wet cloth and then a dry cloth. P.1-5-26
Drum separation claw Check
Replace
- Replace if the leading edge of the claws are
damaged.
P.1-5-27
