Kyocera TASKalfa 520i - Periodic maintenance procedures

2KR/2KS-1
2-4-3
Periodic maintenance procedures
Section
Maintenance
part/location
User call 500K Points and cautions Page
Test copy and
test print
Perform at the maxi-
mum copy size
Test
copy
Test
copy
Section
Maintenance
part/location
User call 500K Points and cautions Page
Paper feed
section
Paper feed pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-3
Separation pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-3
Forwarding pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-3
MP paper feed pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-5
MP separation pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-5
MP forwarding pulley Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
P.1-5-5
MP feed roller 1 Check
Clean
Clean Clean with alcohol.
MP feed pulley Check
Clean
Clean Clean with alcohol.
MP feed roller 2 Check
Clean
Clean Clean with alcohol.
Left registration roller Check
Clean
Clean Clean with alcohol.
Right registration roller Check
Clean
Clean Clean with alcohol.
Feed pulley Check
Clean
Clean Clean with alcohol.
Feed roller 1 Check
Clean
Clean Clean with alcohol.
Feed roller 2 Check
Clean
Clean Clean with alcohol.
Feed roller 3 Check
Clean
Clean Clean with alcohol.
Registration switch Check
Clean
Clean Clean with a dry cloth.
Left registration cleaner Clean Replace Vacuum.
Replace after feeding 500,000 sheets.
P.1-5-10
Registration guide - Replace Replace after feeding 500,000 sheets.
Right registration
cleaner
Clean Replace Vacuum.
Replace after feeding 500,000 sheets.
P.1-5-10
Transfer guide Check
Clean
Replace Clean with alcohol.
Replace after feeding 500,000 sheets.
