L-Acoustics ARCS WIDE Rigging Manual

ARCS
®
WIDE SYSTEM / ARCS
®
FOCUS SYSTEM
rigging manual
VERSION 3.0
ARCSWIFO_RM_EN_3.0 w w w . l - a c o u s t i c s . c o m 14
4.3 Pole-mounting
On feet or on top of SB18m
 Install a WIFOSOCK on an ARCS
®
WIDE/FOCUS enclosure.
Refer to PROCEDURE E.
 Insert the pole into the WIFOSOCK socket.
 If needed, insert the other extremity of the pole into an SB18m socket.
 Tip the assembly to a vertical position.
Dismantling the system
Identify the array to dismount and apply the associated System setup procedure in reversed order.
