L-Acoustics ARCS WIDE Rigging Manual

ARCS
®
WIDE SYSTEM / ARCS
®
FOCUS SYSTEM
rigging manual
VERSION 3.0
ARCSWIFO_RM_EN_3.0 w w w . l - a c o u s t i c s . c o m 8
3 TECHNICAL DESCRIPTION
3.1 Flying
The ARCS WIDE/FOCUS system can using WIFOLIFT or WIFOLIFTBAR depending on two factors:
- number of load-bearing lines,
- number of enclosures.
Follow the indications in this table to know which accessories to use:
1 load-bearing line
2 load-bearing lines
2 or 4 ARCS WIDE / FOCUS
3 or 5 ARCS WIDE / FOCUS
6 ARCS WIDE
6 or 8 ARCS WIDE / FOCUS
1 WIFOLIFT
2 WIFOLIFT + 1 WIFOLIFTBAR
2 WIFOLIFT
3.1.1 WIFOLIFT
Maximum of four enclosures per WIFOLIFT.
Always use 1 load-bearing line per pick-up point.
Only lift symmetrical arrays.
Each side of the array must mirror the other.
1 WIFOLIFT
No bridled suspension on two WIFOLIFT bars.
Always use 1 load-bearing line per pick-up point.
2 WIFOLIFT
