L-Acoustics ARCS WIDE Rigging Manual

ARCS
®
WIDE SYSTEM / ARCS
®
FOCUS SYSTEM
rigging manual
VERSION 3.0
ARCSWIFO_RM_EN_3.0 w w w . l - a c o u s t i c s . c o m 30
Tilt angle reference chart WIFOBUMP (hybrid arrays)
1 SB18m and 2 ARCS
®
WIDE
Rear position
2,4°
-0,8°
-3,9°
-6,6°
-9,1°
-11,7°
-14,2°
-16,6°
-19,0°
-21,3°
-23,6°
-25,8°
-27,9°
-30,3°
-32,6°
Front position
26,6°
24,0°
21,3°
19,0°
16,6°
14,2°
11,7°
9,1°
6,5°
3,9°
1,3°
-1,3°
-3,9°
-7,1°
-10,2°
1 SB18m and 2 ARCS
®
FOCUS
Rear position
0,9°
-2,1°
-5,0°
-7,5°
-9,9°
-12,2°
-14,6°
-16,9°
-19,1°
-21,3°
-23,4°
-25,4°
-27,4°
-29,7°
-31,9°
Front position
24,1°
21,5°
18,9°
16,7°
14,4°
12,1°
9,7°
7,3°
4,8°
2,4°
-0,1°
-2,6°
-5,0°
-8,0°
-10,9°
2 SB18m and 4 ARCS
®
WIDE
Rear position
7,3°
5,6°
3,9°
2,4°
1,0°
-0,4°
-1,8°
-3,3°
-4,7°
-6,1°
-7,5°
-8,9°
-10,3°
-12,0°
-13,6°
Front position
20,7°
19,1°
17,6°
16,3°
15,0°
13,6°
12,3°
10,9°
9,5°
8,1°
6,7°
5,3°
3,9°
2,1°
0,4°
2 SB18m and 4 ARCS
®
FOCUS
Rear position
4,5°
3,0°
1,4°
0,1°
-1,1°
-2,4°
-3,7°
-5,0°
-6,3°
-7,5°
-8,8°
-10,0°
-11,3°
-12,7°
-14,2°
Front position
16,8°
15,4°
14,0°
12,8°
11,5°
10,3°
9,0°
7,8°
6,5°
5,3°
4,0°
2,7°
1,4°
-0,1°
-1,7°
WIFOBUMP
hole
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
