Specications
K3-CHARIOTLID specications
Description
Protective lid for K3-CHARIOT
W
eight (net)
11 kg / 24 lb
Material
high grade steel with anti-corrosion coating
K3-CHARIOTLID dimensions
1031
mm
/ 40.5
in
219
mm
/ 8.6
in
589
mm
/ 23.2
in
118
K3
owner's
manual
(EN)
version
1.0
117
119
