Electro-acoustical description
Preset description
[K3 70] [K3 90] [K3 110] [KARAIIDOWNK3] [KARADOWNK3]
loudspeaker elements outputs channels routing gain delay polarity mute
LF OUT 1 LF ON
HF OUT 2 HF
IN A 0 dB 0 ms +
ON
LF OUT 3 LF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
[KS28_60] [KS28_100] [KS21_60] [KS21_100]
outputs channels routing gain delay polarity mute
OUT 1 SB IN A 0 dB 0 ms + ON
OUT 2 SB IN A 0 dB 0 ms + ON
OUT 3 SB IN A 0 dB 0 ms + ON
OUT 4 SB IN A 0 dB 0 ms + ON
[KS28_60_C] [KS28_100_C] [KS28_60_Cx] [KS28_100_Cx] [KS21_60_C] [KS21_100_C] [KS21_60_Cx]
[KS21_100_Cx]
loudspeaker elements outputs channels routing gain delay polarity mute
SR OUT 1 SR ON
SB OUT 2 SB ON
SB OUT 3 SB ON
SB OUT 4 SB
IN A 0 dB 0 ms +
ON
18 K3 owner's manual (EN) version 1.0
