Rigging procedures
Rigging a Kara II downll array under a K3 array with KARADOWNK3
Type of deployment own array
Rigging accessory KARADOWNK3
Min number of operators 2
About this task
Reference rigging manuals
This procedure is complementary to the rigging instructions available in the main system rigging manuals.
Refer to the Kara II owner's manual for more details.
The following procedure also applies for Kara.
Prerequisite
• Prepare and raise a K3 array. Refer to Flying an array
with K3-BUMP and K3-BAR (p.67).
• Prepare an array of three Kara II with 0° inter-
enclosure angles.
• Position the Kara II array under the K3 array.
Make sure the latches on the bottom K3 are in storage position.
Procedure
1. Take out the four rigging arms on the top Kara II enclosure.
a) Lock the front rigging arms in linking position.
76 K3 owner's manual (EN) version 1.0
