L-Acoustics K Series User Manual

Mechanical safety
Mechanical safety
Flown congurations
The K3 rigging system complies with 2006/42/EC: Machinery Directive. It has been designed following the guidelines
of BGV-C1.
2006/42/EC: Machinery Directive species a safety factor of 4 against the rupture. The own deployments described in
this manual achieve a safety factor of 4 or more.
Refer to Soundvision for the safety factor of a specic deployment.
The safe limit gives the maximum number of elements for which the safety factor is compliant with the 2006/42/
EC: Machinery Directive, within the use dened in this manual and regardless of the other deployment parameters (site
angles, inter-enclosure angles, etc.).
The maximum limit gives the maximum number of elements for which the safety factor can be compliant with the
2006/42/EC: Machinery Directive, when the other deployment parameters provide the best mechanical conditions.
For mixed arrays refer to your Soundvision model.
K3
conguration rigging accessory safe limit maximum limit
K3-BUMP 16 24
K3-BUMP + K3-BAR 16 24
own
K3-BUMP + 2 K3-BAR + 2 LA-
SLING2T + LA-RAKMOUNT
18 K3 + 1 LA-RAK II AVB
24
own and pullback K3-RIGBAR 16 16
K3 + Kara II
conguration rigging accessory safe limit maximum limit
own with a downll KARADOWNK3 12 K3 + 6 Kara II 18 K3 + 6 Kara II
KS28
conguration rigging accessory maximum / safe limit
Flown KS28-BUMP 16
Other congurations
For other congurations, respect the recommended maximum limit for optimal stability.
Use safety straps
Always use safety straps on stacked arrays higher than four enclosures.
K3
conguration rigging accessory safe limit maximum limit
Stacked K3-CHARIOT + K2-JACK 4 6
K3 + KS28
conguration rigging accessory safe limit maximum limit
Stacked K3-TILT + KS28-OUTRIG 5 enclosures 4 K3 + 4 KS28
K3 owner's manual (EN) version 1.0 35
