L-Acoustics K1 User Manual

Loudspeaker congurations
[PRESET]
[K1]
[PRESET]
[K1SB_X]
K1/K1-SB line source
Enclosure K1 K1-SB
Preset [K1] [K1SB_X]
Frequency range (-10 dB) 35 Hz - 20 kHz
Recommended ratio 2 K1 : 1 K1-SB
Minimum line length 8 K1 + 4 K1-SB
When using [K1] with [K1SB_X], do not add any delay value between the K1 and K1-SB elements of a same line
source.
10 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
