Preset description
Preset description
[K1] [K2 110]
loudspeaker elements outputs channels routing gain delay polarity mute
left LF OUT 1 LF ON
right LF OUT 2 LF ON
MF OUT 3 MF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
[KARADOWNK1]
loudspeaker elements outputs channels routing gain delay polarity mute
LF OUT 1 LF ON
HF OUT 2 HF
IN A 0 dB 0 ms +
ON
LF OUT 3 LF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
[K1SB_60] [K1SB_X] [KS28_60] [SB28_60]
outputs channels routing gain delay polarity mute
OUT 1 SB IN A 0 dB 0 ms + ON
OUT 2 SB IN A 0 dB 0 ms + ON
OUT 3 SB IN A 0 dB 0 ms + ON
OUT 4 SB IN A 0 dB 0 ms + ON
[KS28_60_C] [KS28_60_Cx] [SB28_60_C] [SB28_60_Cx]
loudspeaker elements outputs channels routing gain delay polarity mute
SR OUT 1 SR ON
SB OUT 2 SB ON
SB OUT 3 SB ON
SB OUT 4 SB
IN A 0 dB 0 ms +
ON
K1 user manual (EN) version 6.0 23
