L-Acoustics K1 User Manual

Loudspeaker congurations
Additional downll element
All K1 system congurations can be combined with an additional Kara or K2 line source downll system. This allows an
extension of the vertical coverage to the closer audience.
Kara
The [KARADOWNK1] preset features a high-pass lter at 100 Hz for the low section, along with specic delay settings,
in order to optimize the acoustic coupling between the Kara and K1 line sources.
The Kara enclosure is driven by the LA4X / LA8 / LA12X amplied controller.
This section is about Kara downll only.
Refer to the K1 addendum for information about using Kara II as a downll.
Line source with Kara downll system
[PRESET]
[KARADOWNK1]
K1 LINE SOURCE /
K1/K1-SB LINE SOURCE
Enclosure K1 K1-SB in line source Kara
Preset [K1] [K1SB_X] [KARADOWNK1]
Frequency range (-10 dB) 35 Hz - 20 kHz
Kara array Up to 6 Kara enclosures
Do not add any delay between the K1 and Kara elements of a mixed line source.
When using [K1] with [K1SB_X], do not add any delay value between the K1 and K1-SB elements of a same line
source.
Using the Kara system
Refer to the Kara owner's manual for the operating modes of Kara as a main system.
K1 user manual (EN) version 6.0 15

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
