L-Acoustics K1 User Manual

Loudspeaker congurations
K2
The [K2 110] preset provides K2 with the same horizontal coverage as K1 for optimal downll.
The K2 enclosure is driven by the LA4X / LA8 / LA12X amplied controller.
Line source with K2 downll system
[PRESET]
[K2 110]
K1 LINE SOURCE /
K1/K1-SB LINE SOURCE
Enclosure K1 K1-SB in line source K2
Preset [K1] [K1SB_X] [K2 110]
Frequency range (-10 dB) 35 Hz - 20 kHz
Do not add any delay between the K1 and K2 elements of a mixed line source.
When using [K1] with [K1SB_X], do not add any delay value between the K1 and K1-SB elements of a same line
source.
Using the K2 system
Refer to the K2 user manual for the operating modes of K2 as a main system.
16 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
