L-Acoustics K1 User Manual

Technical description
Technical description
K1-SB applications
There are two distinct applications for K1-SB in a K1 system:
• As an LF extension in a line source for enhanced throw, using the [K1SB_X] preset with K1.
• As a subwoofer for increased impact, using the [K1SB_60] preset.
Both applications of K1-SB can be combined in the same conguration.
K1-SB as an LF extension in a line source K1-SB as a subwoofer
K1 LINE SOURCE /
K1/K1-SB LINE SOURCE
K1 LINE SOURCE /
K1/K1-SB LINE SOURCE
ENHANCED THROW INCREASED IMPACT
8 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
