Loudspeaker connection
Loudspeaker connection
Connectors
Kara is equipped with two 4-point speakON connectors.
Internal pinout for L-Acoustics 2-way active enclosures
speakON points 1 + 1 - 2 + 2 -
Transducer connectors LF + LF - HF + HF -
K1 is equipped with two 8-point PA-COM connectors.
IN
LINK
K2 is equipped with two 8-point PA-COM connectors.
IN
LINK
K1 user manual (EN) version 6.0 17
