L-Acoustics K1 User Manual

System components
System components
Loudspeaker enclosures
K1 3-way full-range active WST
®
enclosure
K2 3-way full-range active WST enclosure
Kara 2-way modular WST enclosure
K1-SB K1 system subwoofer 2×15"
SB28 High power subwoofer: 2 x 18''
KS28 Flyable subwoofer 2 x 18''
Powering and driving system
LA8 / LA12X Amplied controller with DSP, preset library and networking capabilities
Refer to the LA8 / LA12X owner's manual for operating instructions.
Racks
LA-RAK Touring rack containing three LA8 and power, audio and network distribution
LA-RAK II AVB Touring rack containing three LA12X, LA-POWER II for power distribution, LA-PANEL II for audio
and network distribution, and two LS10 for AVB distribution
Cables
SP cables 4-point speakON loudspeaker cables (4mm² gauge)
SP cables come in four sizes: SP.7 (0.7m/2.3ft), SP5 (5m/16.4ft), SP10 (10 m/32.8ft) and
SP25 (25m/82ft)
SP-Y1 breakout cable for two passive enclosures (2.5mm² gauge) provided with a CC4FP adapter
4-point speakON to 2 × 2-point speakON
DO 8-point PA-COM loudspeaker cables (4mm² gauge)
DO cables come in three sizes: DO.7 (0.7m/2.3ft), DO10 (10m/32.8ft) and DO25
(25m/82ft)
DOSUB-LA8 breakout cable for four passive enclosures (4mm² gauge)
8-point PA-COM to 4 × 2-point speakON
DOFILL-LA8 breakout cable for two 2-way active enclosures (4mm² gauge)
8-point PA-COM to 2 x 4-point speakON
DO3WFILL breakout cable for one 2-way active enclosure and two passive enclosures (4mm² gauge)
8-point PA-COM to 1 x 4-point speakON and 2 x 2-point speakON
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA8 / LA12X owner's manual for detailed instructions about the whole cabling scheme, including
modulation cables and network.
Rigging elements
Rigging elements or procedures are not presented in this document.
Refer to the K1 rigging manual.
6 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
