L-Acoustics K1 User Manual

Specications
Specications
K1 specications
Description 3-way full-range active WST
®
enclosure , quad-amplied by LA8 / LA12X
Usable bandwidth (-10 dB) 35 Hz - 20 kHz ([K1])
Maximum SPL
1
149 dB ([K1])
Nominal directivity (-6 dB) horizontal: 90° symmetric
vertical: dependent upon the number of elements and the line source curvature
Transducers LF: 2 × 15" neodymium
MF: 4 × 6.5" neodymium, direct-radiating
HF: 3× 3" diaphragm compression drivers
Acoustical load LF: bass-reex
MF: bass-reex
HF: DOSC waveguide
Nominal impedance LF: 2 × 8 Ω
MF: 8 Ω
HF: 8 Ω
Connectors IN: 1 × 8-point PA-COM
LINK: 1 × 8-point PA-COM
Rigging and handling 4 handles integrated into the cabinet
inter-enclosure angles: 0°, 0.5°, 1°, 1.5°, 2°, 2.5°, 3°, 4° or 5°
Weight (net) 106 kg / 234 lb
Cabinet premium grade Baltic birch plywood
high density polyethylene
Front coated steel grill
acoustically neutral 3D fabric
Rigging components high grade steel with anti-corrosion coating
Finish grey brown RAL 8019
IP IP43
1
Peak level measured at 1 m under free eld conditions using pink noise with crest factor 4 (preset specied in brackets).
K1 dimensions
1342 mm / 52.8 in
505 mm / 19.9 in
438 mm / 17.2 in
520 mm / 20.5 in
42 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
