L-Acoustics K1 User Manual

Loudspeaker congurations
Loudspeaker congurations
Line source
Deployed as a line source, the system operates over the nominal bandwidth of the K1 enclosure.
Two congurations are possible:
• K1 line source
• K1/K1-SB line source: enhanced LF throw
By providing the K1-SB with the same frequency response as the K1 low section, the [K1SB_X] preset allows the K1-SB
enclosure to be used as an LF line source element, increasing the length of the sub-low line source.
The K1 and K1-SB enclosures are driven by the LA8 / LA12X amplied controllers.
[PRESET]
[K1]
Standalone K1 line source
Enclosure K1
Preset [K1]
Frequency range (-10 dB) 35 Hz - 20 kHz
K1 user manual (EN) version 6.0 9

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
