L-Acoustics K1 User Manual

Loudspeaker congurations
Delay values
Do not forget to add the pre-alignment and geometric delays depending on the conguration.
When using [K1] with [K1SB_X], do not add any delay value between the K1 and K1-SB elements of a same line
source.
Pre-alignment delays
presets pre-alignment delay values and polarity settings
[K1] + [K1SB_60] K1 = 6 ms K1-SB = 0 ms
Line source with K1-SB behind
[PRESET]
[K1SB_60]
K1 LINE SOURCE /
K1/K1-SB LINE SOURCE
1.5 to 2 m
(5 to 7 ft)
Enclosure K1 K1-SB in line source K1-SB as subwoofer
Preset [K1] [K1SB_X] [K1SB_60]
Frequency range (-10 dB) 30 Hz - 20 kHz
Recommended ratio 1 K1 : 1 subwoofer
Recommended distance
between front panels
Between 1.5 m (5 ft) and 2 m (7 ft)
Delay values
Do not forget to add the pre-alignment and geometric delays depending on the conguration.
When using [K1] with [K1SB_X], do not add any delay value between the K1 and K1-SB elements of a same line
source.
12 K1 user manual (EN) version 6.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
