Loudspeaker connection
Connecting subwoofers
SP and SP-Y1 on speakON output
OUT1/OUT2
OUT3/OUT4
same as OUT1/OUT2
SP SP-Y1
CC4FP
CH(1) (OUT1)
CH(2) (OUT2)
DO and DOSUB-LA8 on CA-COM output
CA-COM
DO
DOSUB-LA8
SPK1 (OUT1)
SPK2 (OUT2)
SPK3 (OUT3)
SPK4 (OUT4)
Connecting 2-way active enclosures
SP on speakON output
SP
OUT1/OUT2 OUT3/OUT4
same as OUT1/OUT2
SP
DO and DOFILL-LA8 on CA-COM output
CA-COM
DO
DOFILL-LA8
SP
2W CH(A) (OUT1/OUT2)
2W CH(B) (OUT3/OUT4)
K1 user manual (EN) version 6.0 21
